Five-Layer Sintered Mesh for Filtration, Purification

Sintered Square and Dutch Woven Mesh - Five Layers

Five-layer sintered mesh is a standard combination of five layers wire meshes with different openings and diameters through sintering (diffusion-bonding) in vacuum, which improves the characteristics of stainless steel woven wire mesh. By bonding the contact points of different wire meshes together, five-layer sintered mesh has become an integrated porous material with enhanced mechanical strength, high permeability and better structural integrity, because the sintering process remains the good filtration rating of the finest mesh layer, also the mechanical strength of the coarser support layers. Besides all of that, heat and pressure are combined to create molecular diffusion-welds at every intersection of the wire mesh where the wires cross over and under one-another, which in turn enhances the temperature and pressure resistance of the sintered mesh. For its distinct features, five-layer sintered mesh is widely used for diffusing, breather vents, filters in many areas such as gas distribution, polyester filtration, water treatment, etc.

Read more

Five-layer sintered mesh front view

Back view of five-layer sintered mesh

Side view of five-layer sintered mesh

Specification

Material: Stainless steel 316 L, stainless steel 304, 304 L, 316, other materials can be made to order.
Filtration accuracy: 1 micron to 200 microns.
Heat resistance: 600 °C.
Standard thickness: 1.7 mm.
Standard size: 480 mm × 480 mm, 480 mm × 980 mm, 500 mm × mm, 600 mm × mm, 610 mm × mm, 610 mm × mm, mm × mm, mm × mm, other sizes can be designed as per customers' demand.
Maximum size: mm × mm.
Type classification: Sintered dutch woven wire mesh and sintered square woven wire mesh.

Feature

Steady filter rating under high pressure.
High mechanical strength.
Easy to be welded, sheared, punched into various shapes.
Good capability of corrosion and abrasion resistance.
Easy to wash, it can be reused for many times.

Five-layer sintered mesh structural drawing, two reinforcing layers and one protective layer contribute stable filtering precision, good strength and easy backwashing.

Five-layer sintered dutch woven wire mesh specification Code Nominal filter rating (µm) Structure Overall thickness (mm) Weight / sq.ft (kg) MIC1L5 1 200 / 400 × / 200 / 12 × 64 / 64 × 12
100 / 400 × / 100 / 12 × 64 / 64 × 12 1. 1. MIC2L5 2 100 / 325 × / 100 / 12 × 64 / 64 × 12 1. 1. MIC5L5 5 100 / 200 × / 100 / 12 × 64 / 64 × 12 1. 0. MIC10L5 10 100 / 165 × / 100 / 12 × 64 / 64 × 12 1. 0. MIC15L5 15 100 / 165 × / 100 / 12 × 64 / 64 × 12 1. 1. MIC20L5 20 100 / 165 × 800 / 100 / 12 × 64 / 64 × 12 1. 1. MIC25L5 25 100 / 165 × 600 / 100 / 12 × 64 / 64 × 12 1. 0. MIC30L5 30 100 / 400 / 100 / 12 × 64 / 64 × 12
100 / 450 / 100 / 12 × 64 / 64 × 12 1. 1. MIC40L5 40 100 / 325 / 100 / 12 × 64 / 64 × 12 1. 0. MIC50L5 50 100 / 250 / 100 / 12 × 64 / 64 × 12 1. 1. MIC75L5 75 100 / 200 / 100 / 12 × 64 / 64 × 12 1. 0. MIC100L5 100 100 / 150 / 100 / 12 × 64 / 64 × 12 1. 0. MIC120L5 120 100 / 120 / 100 / 12 × 64 / 64 × 12 1. 0. Note: 1. Porosity: 37%. 2. MIC: micron, L: layer. Filtration property - five-layer sintered mesh Type Air permeability L/min.dm2 Rating micron (µm) Bubble point pressure (Pa) 8% FP-05 200 2.5 - 7.5 FP-10 250 7.5 - 12.5 FP-15 350 12.5 - 17.5 FP-20 450 17.5 - 22.5 FP-30 550 27.5 - 35 FP-40 650 35 - 45 FP-50 750 45 - 60 860 FP-70 900 60 - 80 690 FP-100 950 80 - 120 630 Note: FP - filtration property, 05 - filter rating is five.

One structural drawing of sintered square woven wire mesh, the protective and reinforcing layers contribute to rigidity.

Specification - five-layer sintered square woven wire mesh Code Structure Thickness (mm) Weight (kg/m2) Porosity (%) FSWM - 1.9 30 / Filter layer / 60 / 20 / 16 1.9 5.3 52 FSWM - 2.5 80 / Filter layer / 30 / 10 / 8.5 2.5 8.8 55

Note

Filter rating varies from 2 µm to 200 µm, the filtration layer is selected as per customers' need.
The porosity takes 20 mesh as criteria.

Application

Typical applications of five-layer sintered mesh include filtration of polymer, food, water, cosmetic, pharmacy, chemicals and hydraulic fuels. It is also used for fluidization of bulk materials in wagons, conveyors, driers, coolers and storage silos.

Products Display

Five-layer sintered mesh rectangular sheets

5-layer sintered mesh round discs

Five-layer sintered mesh filter cartridge

Five-layer sintered mesh filter cartridge front view

Side view of a five-layer sintered mesh filter cartridge

Five-layer sintered mesh filter cartridge inside

Five-layer sintered mesh filter cartridge packaging

Packed five-layer sintered mesh panels

Round five-layer sintered mesh

Five-layer sintered filter element

Extended five-layer sintered filter element

FAQs

Polymer filtration, petrochemical and refining, pharmaceutical production, natural gas, new energy and other industries, or the treatment of dust particles such as metal powders/vapors, gelled particles, carbon powder, talcum powder, plant spores, bacteria, and other dust particles.

We can design and customize five-layer sintered mesh products according to your specific needs. Just provide us with the following basic information: shape, application, mounting structure, flow rate, pressure drop, working pressure, working temperature, and material, and then our experienced engineers will provide you with suitable solutions for your reference and choice.

It can withstand high temperatures up to 480 °C at room temperature and 600 °C at transient temperature.

Five-layer sintered mesh flow rate characteristics:

Standard materials SS304, SS304L, SS316, SS316L. We can also customize special alloys such as Hastelloy C-276, Monel Alloy 400, Inconel 600, SS904, SS904L, Duplex stainless steel , etc.

It can be cleaned by countercurrent water, filtering, ultrasonic, melting, baking, etc. It is especially suitable for backwashing.

Backwashing of sintered mesh is achieved by pressurising the mesh from within the machine and quickly opening the backwash square valve during the backwash. The backwash generates a high reverse homeopathic pressure differential, which effectively removes contaminants from the element surface.

Sintered mesh is made from multiple layers of metal mesh through a diffusion solid solution sintering process. Its basic process flow is:

Mesh structure design. The sintered mesh must meet the requirements of the filter system. Therefore, before production, it is necessary to reasonably customize its filter rating, thickness, number of layers, single-layer metal mesh structure, and material to ensure it meets the needs of the existing current filter systems.
Mesh pre-treatment. Stack single-layer metal mesh.
Ultrasonic cleaning. Sintered mesh has good backwashing properties. Through ultrasonic cleaning, excess impurities on the surface of the single-layer metal mesh can be removed, making its surface smooth and facilitating subsequent sintering.
Vacuum sintering. The cleaned stacked sintered mesh is placed in a vacuum sintering furnace for pressing. When the temperature reaches 1,100 °C, a diffusion solid solution process is employed to ensure that the mesh opening channels are not easily deformed and that the surface is smooth, thereby guaranteeing stable filtration precision of the sintered mesh. At the same time, after the pressing and sintering process, the sintered mesh possesses high mechanical strength and overall rigidity;
Cutting. When the sintering is completed, suitable dimensions are cut out through machining.
